IV Catheters:

Product Basic Specification

Blood Control : Y

Catheter Gauge Size : 20 G

Catheter Length : 1.75 in.; 44 mm

Catheter Inner Diameter (I.D.) Size : 0.83 mm

Catheter Outer Diameter (O.D.) Size : 1.10 mm

Gravity Flow Rate : 51 mL/min

High Pressure Rating : 300 psi

Hub Color : Pink

Sterilization Method : ETO

Quantity : Box of 20

Product Basic Specification

Catheter Gauge Size : 20 G

Catheter Length : 1.25 in.; 32 mm

Catheter Inner Diameter (I.D.) Size : 0.83 mm

Catheter Outer Diameter (O.D.) Size : 1.10 mm

Gravity Flow Rate : 58 mL/min

High Pressure Rating : 300 psi

Hub Color : Pink

Sterilization Method : ETO

Quantity : Box of 20

Product Basic Specification

Blood Control: Y

Catheter Gauge Size : 18 G

Catheter Length : 1.25 in.; 32 mm

Catheter Inner Diameter (I.D.) Size : 0.98 mm

Catheter Outer Diameter (O.D.) Size : 1.31 mm

Gravity Flow Rate : 84 mL/min

High Pressure Rating : 300 psi

Hub Color : Green

Sterilization Method : ETO

Quantity : Box of 20

Product Basic Specification

Blood Control : Y

Catheter Gauge Size : 18 G

Catheter Length : 1.75 in.; 44 mm

Catheter Inner Diameter (I.D.) Size : 0.98 mm

Catheter Outer Diameter (O.D.) Size : 1.31 mm

Gravity Flow Rate : 79 mL/min

High Pressure Rating : 300 psi

Hub Color : Green

Sterilization Method : ETO

Quantity : Box of 20

Jelco Intravenous Catheter features a thin wall that facilitates higher flow rates, allowing for the use of a smaller gauge.

• The FEP polymer and J-point needle design allows the clinician to "feel" the vein entry.
• Color coding indicates catheter gauge at a glance.
• Translucent hub for easy flashback visualization.
• Advanced tip design allows for smoother vein entry.
• Sharp introducer needle for easy insertion.
• Thin wall design provides higher flow rate.
• J-point needle design.
• Excellent trim accuracy allows smoother vein access.

Provides medical staff with higher certainty of catheter placement due to unique flashback feature. Improves visualization for difficult venipunctures.

• Material: Polyurethane.
• Extremely flexible.
• Kink-resistant.
• Durable.

• Surshield Safety Winged Infusion Set
• No change in needle insertion technique required
• Minimizes the risk of needlestick injuries
• Simple, built-in safety design is easy to use
• Latex-free and DEHP Free

Featuring a unique one-handed needle locking mechanism, Surshield safety winged infusion sets help reduce the risk of needle stick injuries in a cost-effective, intuitive way. The shield simply presses over the needle and locks into place with an audible click, allowing safe use without the need to change insertion technique.

Details

• Surshield Safety Winged Infusion Set
• No change in needle insertion technique required
• Press shield over the needle until it locks into place
• Minimizes the risk of needlestick injuries
• Simple, built-in safety design is easy to use
• Latex-free
• DEHP Free
• Sold as a box of 50

BD Angiocath™ Special IV Catheter 12 G x 3.00 in.

Featuring both BD Needle Technology and a tapered catheter tip, these BD IV Catheters ensures a smooth and simple insertion.

• Thin-wall design.
• Tapered Tip.
• Smooth Insertion.
• Optimal Flow Rate.
• With thermo-molded bevel.
• Triple-bevel Needle.
• Transparent clear flashback chamber.
• Luer-Lok™ compatible.
• Material: FEP Polymer.
• DEHP-Free.
• Sterile.
• Latex-Free.

Product Basic Specification

Catheter Gauge Size : 14 G (2.1 mm)

Catheter Inner Diameter (I.D.) Size : 1.588 mm

Catheter Length : 1.88 in (48)

Catheter Outer Diameter (O.D.) Size : 2.108 mm

Gravity Flow Rate : 277 mL/min

Hub Color : Orange

Sterilization Method : EO

BD Insyte-W peripheral venous catheter (1.3 mm x 30 mm) made of BD Vialon biomaterial. Has wings and a notched needle.

BD Vialon, a unique proprietary biomaterial, has been proven to enhance clinical and economic outcomes.

• Increases the ease of penetration
• Reduces the risks of infiltration
• Exhibits greater kink resistance
• Reduces the risks of phlebitis by up to 50%
• Reduces IV restarts due to reduced complications
• Increases indwelling time
• Reduces the total IV therapy costs used due to longer indwelling times

Stabilizing wings provide a large surface area for taping down the catheter improving catheter securement.

Key Features BD 381344:

• Catheter Gauge: 18 G
• Catheter Gauge (m): 1.3 mm
• Catheter ID (in): 0.0370-0.0400 in.
• Catheter ID (m): 0.940-1.016 mm
• Catheter Length (in): 1.16 in.
• Catheter Length (m): 30 mm
• Catheter Material: BD Vialonâ„¢ biomaterial
• Catheter OD (in): 0.0500-0.0530 in.
• Catheter OD (m): 1.270-1.346 mm

BD Insyte™ IV Catheter 18 G x 1.16 in. (1.3 mm x 30 mm) with BD Vialon™ Catheter Material, sterile, single use

Reduces the risks of phlebitis up to 50%. Increases indwelling time and ease of penetration.

• Made of Vialon™ biomaterial.
• Reduces risk of Infiltration and IV restart.
• Greater kink resistance.
• Sterile.
• Latex-Free.
• Disposable.

BD Insyte™ IV Catheter 20 G x 1.16 in. (1.1 mm x 30 mm) with BD Vialon™ Catheter Material, sterile, single use

Reduces the risks of phlebitis up to 50%. Increases indwelling time and ease of penetration.

• Made of Vialon™ biomaterial.
• Reduces risk of Infiltration and IV restart.
• Greater kink resistance.
• Sterile.
• Latex-Free.
• Disposable.
